Titan Dynamics Falcon V2 - Table of Contents

Titan Dynamics
Titan Dynamics Webpage
Visit our Facebook page
Join our Discord server
Page
2
of
30
Contents
Section 1: Model Information ................................................................................................................ 3
Section 2: Model Specifications & Performance ............................................................................. 4
2.1: Physical Characteristics ............................................................................................................... 4
2.2: Aircraft Performance: .................................................................................................................. 5
2.2.1: Drag, Efficiency, Power, and Angle of Attack at Varying All-up-weights: ............. 6
2.2.2: Turn rate, range, endurance, and max climb rate for a variety of different
battery configurations: ................................................................................................................ 11
Section 3: Required Build Materials .................................................................................................. 14
Section 4: 3D printing ........................................................................................................................... 15
4.1: Things to know before you start printing. .......................................................................... 15
4.2: Part Orientation .......................................................................................................................... 16
4.3: Tuning “hole horizontal expansion” ....................................................................................... 18
4.4: Bed Adhesion and warping ...................................................................................................... 18
Section 5: Assembly of 3D Printed Parts ......................................................................................... 19
Section 6: Final Setup & Tuning Tips ................................................................................................. 25
Section 7: Additional Images .............................................................................................................. 26
