Page 12 of 28
Section 3: Required Build Materials
Spars needed:
• (2) 16x230mm Front motor arms
• (1) 16x600 Tail boom
• (2) 10x1000mm Main wing
• (2) 8x500mm Wing support
• (2) 4x400mm Aileron hinge
• (2) 4x100mm Landing leg spar
• (4) 3x280mm Tail surface spars
Recommended motor and prop: Brotherhobby Tornado T5 3115 640kv | APC 13x8E/ APC
13x8EP – this prop is not meant to hover for long, and is optimized for forward flight. If
you want to hover longer use a 12x6.
Tilt Servo:
20kg Dual output servo with metal brackets. There are many variants of this, use best
judgement if the exact one linked below is not available in your area.
https://amzn.to/3UFCKbv
https://www.aliexpress.us/item/3256804872953262.html
Recommended electronics:
• TBS crossfire / ELRS / Dragonlink / SIYI HM30 or MK15
