Rack Control Module
TM
Product Manual
Rev. 1.2, May 9, 2014 Page 36
TPM 007
For Single or Dual TD80 Systems:
Permit: RED
Sensor 1: RED
Sensor 2: OFF
Power: SOLID YELLOW
WHAT TO DO:
DETAILS:
WHAT TO CHECK:
REMEDY:
Check the Finch
display for an
active alarm,
system error
code or loss of
communication
Clear the alarm
or resolve the
TD80 system
malfunction
If the alarm
clears, no system
errors or loss of
communication
and Sensor 1
remains RED
1. Check for loose
or broken wiring
at the RCM
junction box.
Repair or replace
the wiring.
2. Check the wiring
between the
junction box and
RCM. Repair the
wiring or replace
the RCM
For Single or Dual TD80 Systems:
Permit: DIM RED, BLINKING
Sensor 1: DIM RED, BLINKING
Sensor 2: DIM RED, BLINKING
Power: DIM RED, BLINKING
WHAT TO DO:
DETAILS:
WHAT TO CHECK:
REMEDY:
Check for
incorrect
wiring of SV
input and
power input
One or Two
SV channels
are switched
with RCM
Power Input
If test light on SV
input does not
blink after first 10
second of power
up, this is likely
power connected
to the wrong
input .
Correct wiring to ensure
SV from TD80 goes to
RCM SV Input,and power
goes to RCM Power Input
