Titan Logix Rack Control Module - 5 Technical Reference; Figure 5-1: RCM Dimensions; Rack Control Module Kit Components; Specifications

Rack Control Module
TM
Product Manual
Rev. 1.2, May 9, 2014 Page 42
TPM 007
5 Technical Reference
Rack Control Module Kit Components: 5.1
 Rack Control Module
 Dual sockets with built-in ground bolt
 Thermistor 6-Way Dummy and Optical Booster (Optic-only
model does not include thermistor socket with dummy)
 Installation Manual
 Quick Reference Operator Guide
Specifications: 5.2
Power: 8-30 VDC
Current Consumption: 40mA at 12V
Ambient Temperature Range: -40C to +40C
Communications: TD80 SVBus
Environment: Hazardous area approvals
Class I, Div. 2, Groups C & D, T3
Intrinsically safe associative
Weatherproof- NEMA 4 or Type 4
Dimensions:
Figure 5-1: RCM Dimensions
