Titan LX-75 User Manual

English
 4 ©TitanToolInc.Allrightsreserved.
Warranty
TitanTool,Inc.,(“Titan”)warrantsthatatthetimeofdeliverytotheoriginalpurchaserforuse(“EndUser”),theequipmentcoveredbythiswarrantyisfreefrom
defectsinmaterialandworkmanship.Withtheexceptionofanyspecial,limited,orextendedwarrantypublishedbyTitan,Titan’sobligationunderthiswarranty
islimitedtoreplacingorrepairingwithoutchargethosepartswhich,toTitan’sreasonablesatisfaction,areshowntobedefectivewithintwelve(12)monthsafter
saletotheEndUser.ThiswarrantyappliesonlywhentheunitisinstalledandoperatedinaccordancewiththerecommendationsandinstructionsofTitan.
Thiswarrantydoesnotapplyinthecaseofdamageorwearcausedbyabrasion,corrosionormisuse,negligence,accident,faultyinstallation,substitutionofnon-
Titancomponentparts,ortamperingwiththeunitinamannertoimpairnormaloperation.
DefectivepartsaretobereturnedtoanauthorizedTitansales/serviceoutlet.Alltransportationcharges,includingreturntothefactory,ifnecessary,aretobe
borneandprepaidbytheEndUser.RepairedorreplacedequipmentwillbereturnedtotheEndUsertransportationprepaid.
THEREISNOOTHEREXPRESSWARRANTY.TITANHEREBYDISCLAIMSANYANDALLIMPLIEDWARRANTIESINCLUDING,BUTNOTLIMITEDTO,THOSEOF
MERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSE,TOTHEEXTENTPERMITTEDBYLAW.THEDURATIONOFANYIMPLIEDWARRANTIESWHICH
CANNOTBEDISCLAIMEDISLIMITEDTOTHETIMEPERIODSPECIFIEDINTHEEXPRESSWARRANTY.INNOCASESHALLTITANLIABILITYEXCEEDTHEAMOUNTOF
THEPURCHASEPRICE.LIABILITYFORCONSEQUENTIAL,INCIDENTALORSPECIALDAMAGESUNDERANYANDALLWARRANTIESISEXCLUDEDTOTHEEXTENT
PERMITTEDBYLAW.
TITANMAKESNOWARRANTYANDDISCLAIMSALLIMPLIEDWARRANTIESOFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSEWITHRESPECTTO
ACCESSORIES,EQUIPMENT,MATERIALSORCOMPONENTSSOLDBUTNOTMANUFACTUREDBYTITAN.THOSEITEMSSOLD,BUTNOTMANUFACTUREDBYTITAN
(SUCHASGASENGINES,SWITCHES,HOSES,ETC.)ARESUBJECTTOTHEWARRANTY,IFANY,OFTHEIRMANUFACTURER.TITANWILLPROVIDETHEPURCHASER
WITHREASONABLEASSISTANCEINMAKINGANYCLAIMFORBREACHOFTHESEWARRANTIES.
Parts List
Item Part # Description Quantity
 1 520-099 Diuser,“G”thread............................1
 2 651-020 Sealwasher ..........................................1
 3 711-010 Polemount ........................................... 1
 4 611-652 Retainingnut,“G”thread ................1
 5 611-418 Tipswivelassembly,“G”thread ....1
 6 651-020 Tipseal ...................................................1
 7 661-517 Tipassembly,SC6 ..............................1
 8 661-012 Tipguard,“G”thread ........................ 1
 9 651-040 Tipsealretainer ..................................1
 10 550-514 Ballholderassembly ......................... 1
 11 580-513 Triggerscrew,short ...........................1
 12 550-466 O-ring .....................................................1
 13 550-456 Gunheadtting .................................1
 14 550-437 Sealwasher ..........................................1
 15 550-458 Packingsealassembly ...................... 1
 16 226-001 Locknut ................................................. 1
 17 550-464 Extensionpoleassembly,4’ ...........1
  550-501 Extensionpoleassembly,8’
 18 580-530 Swivelassembly .................................1
 19 550-488 Filterspring ..........................................1
 20 550-483 Filter,medium ..................................... 1
 21 580-531 Gunhandle ........................................... 1
 22 560-038 Handleseal ........................................... 2
 23 550-448 Gunhead ...............................................1
 24 550-454 Triggerscrew,long ............................ 1
 25 550-455 Trigger ....................................................1
 26 550-452 Triggerguard .......................................1
 27 0286932 4’needleassembly ............................1
  0286933 8’needleassembly ............................1
  550-521 Gunrepairkit(includesitems12
and14–16)
  550-518 Diuser/ballholderrepairkit,“G”
thread
   (includesitems1,10,and12)
  651-139 Tipguardandswivelassembly,“G”
thread
   (includesitems2–5and8)
  0286937 Majorrepairkit,4’(includesitems
10,12,14-16and27)
  0286938 Majorrepairkit,8’(includesitems
10,12,14-16and27)
1
17
2
3
4
5
6
9
10
11
12
13
14
15
16
7
8
18
27
19
20
21
22
23
24
25
26
