Titan Performance Series 450e0558067 User Manual

Performance Series 450e 7
GB
Description of unit
3
4
5
6
7
10
11
12
13
9
1
2
8
3.3 Legend for explanatory diagram Performance Series 450e
1 Spray gun
2 High-pressure hose
3 Return hose
4 Suction hose
5 Frame
6 Drip cup
7 Power cord
8 Relief valve
  Leverpositionvertical–PRIME(kcirculation)
  Leverpositionhorizontal–SPRAY(p)
9 Pressure control knob
 10 ON/OFFswitch
11 Circuit breaker
12 Pressure gauge
 13 OilcupforPistonLube(PistonLubeprevents
  increasedwearofthepackings)
3.4 Explanatory diagram Performance Series 450e

Titan Performance Series 450e0558067 Specifications

General

Brand	Titan
Model	Performance Series 450e0558067
Category	Paint Sprayer
Language	English
