Titon TP408HMBE - Wiring Diagrams

TPxxxHMB/HMBE Units ONLY
Wiring Diagrams
Supply
auralite®
0V
12V
A
B
0V
12V
A
B
auralite® connection at Indicator ref EE180
auralite® connection at Unit ref EE180
0V
12V
A
B
0V
12V
A
B
Double Pole Isolator Fuse
L
N
L
N
Mains cable must be separate
from the communication cables.
See Important Information.
230V~
Supply wiring diagram 230V~ ref EE141
13
