Installation Manual-DISPLACEMENT VENTILATION DIFFUSERS
Redefine your comfort zone. ™ | www.titus-hvac.com
DVBC Duct Cover Installation (continued)
STEP 4
Mount the mounting fixture assembly on the top of the unit.
STEP 5
Slide the duct cover in-between the mounting strip and the aluminum strip
and assemble it to the brackets using screws. Snap the décor strips into
the springs of the extension and duct cover assemblies.
Figure 4
Figure 5
