4. NOMENCLATURES AND FUNCTIONS
[Rear Panel]
[Front Panel]
For A-3000D-AS Series, A-3000DM-AS Series & A-3000DMZ-AS Series
[Rear Panel]
[Front Panel]
For A-3248DME-AS
1. Power Switch
Press to turn ON the power.
Press again to turn off the power.
2. Power Indicator
Lights green when power is switched on.
3. Protect Indicator
Lights when protect function activated.
4. Signal Indicator
Lights green for indicates present of an output
signal.
5. Peak Indicator
Lights red to indicate the output signal reaches the
peak level, this indicates that sound is distorted. In
such case, adust each volume control to reduce
output level.
