Toa P-75D - Precautions

Precautions ..................................................... 1
General Description ........................................ 2
Features ................................................ 2~ 3
Specifications .......................................... 4~ 6
Performance Graphs .................................... 7~12
Front Panel ............................................. 13~14
Rear Panel .............................................. 15~16
Input/Output Connections ............................... 17~22
Installation Precautions .................................23~26
Appearance ................................................ 27
1. XLR type audio connectors are factory wired as follows.
Pins 1 and 2 are ground (shield); pin 3 is hot (high, plus).
The connector wiring changes with use of an optional matching transformer.
(Model No. PU-101T)
Pin 1 is ground (shield), Pin 2 is cold (low, minus), and pin 3 is hot (high,
plus).
2. Care should be taken in making connections, selecting signal sources and
controlling the output level to avoid any damage to loads.
3. Never parallel the two amplifier outputs together.
4. Do not operate the amplifier from power mains which exceeds the indicated
mains voltage by more than 10%.
5. Never connect the output of the amplifier to any other power source.
6. Do not expose the amplifier to corrosive chemicals or liquids such as, soft
drinks, salt water, etc.
7. Always refer the amplifier to qualified technical service personnel. There
are no user servicable parts inside.
