22
5.6. Expansion Unit TS-918
10 12
[Left side]
12. Headphone volume control
Adjusts the output volume of the left-side
headphone output.
1
2
[Front]
1. Power indicator
Lights when connecting the supplied AC adapter to
the DC inlet on the rear panel.
2. Connection status indicators
The corresponding LINE indicator lights when the
TS-919B4 or TS-919B1 Bridge unit is connected
to the Bridge unit connection terminal on the rear
panel and power is supplied to it.
