6.2.InstallingtheVX-200SEintheVX-200SZ-2andVX-200SP-2
• A 9-band, single-channel equaliser function can be added by installing the VX-200SE Equaliser Card in the
VX-200SZ-2 Impedance Detection Module or the VX-200SP-2 Pilot Tone Detection Module.
• InthePCsoftwaresettings,"EQ"mustbesettoONfortheVX-200SZ-2andtheVX-200SP-2inwhichthe
VX-200SE is installed. For details, refer to the VX-2000 series Instruction manual.
• UsethePCsoftwaretoperformequalisersetting.Fordetails,refertotheVX-2000seriesInstructionmanual.
VX-200SP-2 or VX-200SZ-2
VX-200SE
