12.1. Pilot Tone Detection Module VX-200SP-2
[End-of-line unit (accessory)]
•Optionalproduct
Equalisercard:VX-200SE
•Accessories
Plug-in screw terminal ............................... 1
End-of-line unit .......................................... 1
Note: The design and specifications are subject to change without notice for improvement.
12. SPECIFICATIONS
Power Source Supplied from VX-2000SF
Current Consumption Under100mA
Power Amplifier Link RJ45 female connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Twisted-pair straight cable (TIA/EIA-568A standard)
Line Monitor Plug-in screw connector
Applicablecablediameter:AWG24–AWG16
External Attenuator
Control output
Plug-in screw connector, relay, no-voltage make contact output,
transfertype,withstandvoltage:30VDC,250VAC,
contactcurrent:Under7A(DC),under7A(AC)
Applicablecablediameter:AWG24–AWG16
Speaker Output Plug-in screw connector
Applicablecablediameter:AWG24–AWG16
Power Amplifier Input
Plug-in screw connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Applicablecablediameter:AWG24–AWG16
Fault Detection System Short circuit, open circuit (pilot tone detection method), ground fault
Finish Panel:Surface-treatedsteelplate
Dimensions 30.5 (w) x 132.6 (h) x 290.3 (d) mm
Weight 235 g
Applicable Model VX-2000SF
Power Source SuppliedfromVX-200SP-2(Generatedby40Hzsinewave)
Speaker Line Input Screwconnector,Applicablecablediameter:AWG24–AWG16
Operation Mode Normal: Terminatedby470kΩbetweenthespeakerlineandtheshield
Open: Openedbetweenthespeakerlineandtheshield
Dimensions 70 x 45 mm
Weight 22 g
