12.2. Impedance Detection Module VX-200SZ-2
•Optionalproduct
Equalisercard:VX-200SE
•Accessory
Plug-in screw terminal ............................... 1
Note: The design and specifications are subject to change without notice for improvement.
Power Source Supplied from VX-2000SF
Current Consumption Under170mA
Power Amplifier Link RJ45 female connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier.
Twisted-pair straight cable (TIA/EIA-568A standard)
External Attenuator
Control Output
Plug-in screw connector, relay, no-voltage make contact output,
transfertype,withstandvoltage:30VDC,250VAC,
contactcurrent:Under7A(DC),under7A(AC)
Applicablecablediameter:AWG24–AWG16
Speaker Output 2 outputs (A, B), plug-in screw connector
Applicablecablediameter:AWG24–AWG16
Power Amplifier Input Plug-in screw connector for connecting the VP-2000 series or VP-3000 series
Power Amplifier
Applicablecablediameter:AWG24–AWG16
Fault Detection System Short circuit, open circuit (impedance detection method), ground fault
Finish Panel:Surface-treatedsteelplate
Dimensions 30.5 (w) x 132.6 (h) x 290.3 (d) mm
Weight 335 g
Applicable Model VX-2000SF
