10
Step 1.
mounted AC inlets (IN1 and IN2).
Step 2.
Note
should contact the unit chassis or equipment rack.
Step 3. Connect the negative battery cable to the negative terminal in the same manner as Step 2.
VX-3000DS
Tightening torque: 6 – 8 Nm
3
2
Cable cross
sectional area
16 mm
2
25 mm
2
35 mm
2
50 mm
2
180 cm
280 cm
400 cm
570 cm
AWG 6
AWG 4
AWG 2
AWG 0 (AWG 1/0)
80 cm each
130 cm each
190 cm each
275 cm each
20 cm
20 cm
20 cm
20 cm
AWG
Example of wire length
Cable A, Cable C Cable B
VX-3000DS’ Battery connection terminals
Battery terminals
6 – 8 Nm
4.1 – 5.6 Nm (M6)
8.2 – 5.6 Nm (M8)
Battery connnection terminals
Battery
Cable A
Cable C
Cable B
Battery
VX-3000DS
TEMPERATURE
SENSOR
24V(16-25V)
POWER OUT
MAX 0.3A
IN
OUT
DS LINK
wire, terminal, fuse, and terminal points.
For reference, refer to each resistance as follows.
torque as shown below.
