Toa VX-3000DS CE - Connecting the VX-3000 DS to VM-3000 System

17
5.3. Connecting the VX-3000DS to VM-3000 System
VX-3000DS
VP-2241
PA LINK VP-200VX
28 V 4.8 A
DC POWER IN
PA OUT (SP LINE)
C H
TEMPERATURE
SENSOR
24V(16-25V)
POWER OUT
MAX 0.3A
IN
OUT
DS LINK
RJ45 male connector
AWG 6 – AWG 0 (1/0)
VM-3240VA/3360VA
From
VX-3000DS
From VX-3000DS
From VX-3000DS
Note
Remove the short bar attached at the factory.
230 V AC
220 V AC
50/60 Hz
230 V AC
220 V AC
50/60 Hz
230 V AC
220 V AC
50/60 Hz
Lead-acid Battery
(–)
(+)
+
VP-3000 series power amplifier
VM-3240E/3360E
-
+
-
Cat.5
STP
a
ef
c
d
b
(–)
(+)
From
VX-3000DS
m k gi
n l hj
ikm ag ce
jln bh df
(–)
(+)
Note
The maximum number of the devices connected to and the output power supplied from one VX-3000DS must

 Total number of the connected devices Total output power
VP-3154, VP-3304, VP-3504 Max. 8 channels 2000 W or less
