3-2
Chapter 3 OPERATION
1. BGM AND GENERAL BROADCAST
1.1.BroadcastingfromtheRM-200SF,RM-300X,RM-320F,andRM-210F
The function keys of the remote microphone can be used to make microphone announcements, to change or
end BGM broadcasts, and to activate or end general-purpose and general EV broadcasts.
For instructions on assigning functions to function keys, see the separate Setting Software Instructions, "EVENT
SETTINGS."
The example here shows the RM-300X, but the basic operation and displays are the same for the RM-200SF,
RM-320F, and RM-210F.
1.2.AssignmentExample
[Settingexampletofunctionkeys]
Key Item Name Function
Function key R1 Zones 1, 2 and 3 Zone selection (pattern)
Function key R2 Zone 1 Zone selection (individual)
Function key R3 Zone 2 Zone selection (individual)
Function key R4 Zone 3 Zone selection (individual)
Function key R5 Zone clear Clear pre selected zones
Function key R6 General broadcast pattern 1 Activation and end of general broadcast pattern 1 broadcast
Function key R7 General EV broadcast Activation and end of general/BGM broadcast
Function key R8 Zone 1 volume up Zone volume adjustment (pulse)
Function key R9 Zone 1 volume down Zone volume adjustment (pulse)
Function key 11 Input 1 volume up Input volume adjustment (pulse)
Function key 12 Input 1 volume down Input volume adjustment (pulse)
Function key L1 BGM pattern 1 Activation of base pattern 1 broadcast
Function key L2 BGM pattern 2 Activation of base pattern 2 broadcast
Function key L3 BGM end Interrupt base broadcast pattern
Talk key Lock type, Start Chime: 1, End Chime: None
RM-300X
Function key R1
Function key R2
Function key 11
Function key 12
Function key R3
Function key R4
Function key R5
Function key R6
Function key R7
Function key R8
Function key R9
Talk key
Function key L1
Function key L2
Function key L3
