PARTS NAME
ENOM00303-0
MF, EF, EP, EFT, EPT
1
2
3
8
9
11
10
13
14
15
16
17
18
23
20
19
21
22
12
4
5
6
7
27
28
29
26
25
24
ENOF01202-0
1 Tilt Handle
2 Top C o wl
3 Bottom Cowl
4 Cooling Water Check Port
5 Power Tilt Switch
*1
(EPT and EFT type only)
6 Oil Drain Bolt
7 Anti Ventilation Plate
8 Anode/Trim Tab
9 Sub Water Inlet
10 Water Inlet
11 Propeller
12 Drive Shaft Housing
13 Thrust Rod
14 Clamp Bracket
15 Clamp Screw
16 Throttle Grip
*2
17 Shift Lever
*2
18 Starter Handle
19 Stop Switch
20 Warning Lamp
21 Fuel Connector
22 Starter Switch
*3
23 Choke Knob
*2
24 Water Plug
25 Oil Plug (Upper) (Level)
26 Oil Plug (Lower) (Fill)
27 Oil Filter
28 Spark Pulg
29 Oil Filter Cap
*1: Power tilt type only.
*2: Tiller handle type only.
*3: Electrical starter type only.
