82
13
PROPELLER TABLE
ENOM00329-0
Use a genuine propeller.
A propeller must be selected so that the engine rpm measured at wide open throttle while
cruising is within the recommended range.
15: 5000–6000 rpm
20: 5400–6100 rpm
Propeller
Mark
Propeller Size (Blades × diameter × pitch)
inch mm
Light boats 11.5 3 × 9.25 × 11.5 3 × 235 × 292
10 3 × 9.25 × 10 3 × 235 × 254
9 3 × 9.25 × 9 3 × 235 × 229
8 3 × 9.25 × 8 3 × 235 × 203
7 3 × 9.2 × 6.9 3 × 234 × 174
6 3 × 9.2 × 6.1 3 × 234 × 155
Heavy boats 7 4 × 10 × 4 4 × 254 × 178
MFS15-20D_EUR_EN_141119N.book 82 ページ ２０１４年１２月２３日 火曜日 午後６時４１分
