INSPECTION AND MAINTENANCE78
10
ENOM00088-A
Anode replacement
A sacrificial anode protects the outboard motor from electrolytic corrosion. Anode is
located on the gear case, cylinder etc.. When the anode is eroded more than 1/3 of
original size, replace it.
ENON00029-0
Notes
z Never grease or paint the anode.
z At each inspection re-tighten the anode attaching bolt. As it is likely to be subjected to elec-
trolytic corrosion.
*1 : Both side
*2 : Remove fuel filter to access the anode.
ENOF01125-A1
*1
*2
