8/35
<Err 1 to 5>
Error in membrane switch
Turn off the power once and turn it on again without touching any keys.
-If error disappears, then is operates normally.
-If not, contact TOHNICHI or the nearest distributor to ask for repair.
<Err 8>
Error in data memory
-Contact TOHNICHI or the nearest distributor to ask for repair.
<Err 9>
Error in the circuit board or the torque sensor
At no load condition, press “C” key.
-If “Err9” disappears, then it operates normally.
-If not, contact TOHNICHI or the nearest distributor to ask for repair.
4.5. Auto memory/ reset
After tightening or measuring, the values are automatically saved and forward to the
counter to the next. Auto memory timing can be selected from 0.1 to 5 seconds.
If you do not want to use auto memory function, set it as 0.0 seconds.
4.6. Judgment
Set the torque, angle, double tightening detection angle and direction of tightening,
these judge whether the measured result are within the range or not.
Under the Tightening mode (MODE-T), when you set the high/ low torque and angle,
double tightening detection angle, and direction of tightening, the tool gives the
beep intermittent and blue LED if the torque value reaches about 80% of low limit
torque. Once reaches on low limit torque value the tool give beep continuous and
red LED.
Under the Inspection mode (MODE-M), if you set the high and low limit torque
values the tool makes judgment the measured torque result.
If you set the Auto memory/ reset, the judgment is made automatically.
4.7. Mute
By setting “Off” on buzzer output setting, the buzzer sound on key operation will be
turned off. However, over-torque alarm, tightening completion, NG judgment alarm
remains effective.
4.8. Electric power saving
When it is left without any key operation of tightening operation for about 1 minute
7-segment LED darkens to save electricity. This mode is available when Auto power
off is set ON.
