14/35
6. Power operation and connection for Bluetooth®
・ When press "Power" switch to turn on the tool the Bluetooth® powers on and the
red power LED turns on.
・ To turn off the Bluetooth® power, press and hold the “Power” switch more than 2
seconds during the tool power is on. (If press a “Power” switch the tool display only
turns off)
Please turn off the Bluetooth® power while not in use to save the battery.
・ When the Auto power off feature works the display turns but the Bluetooth® power
is on.
・ When the Bluetooth® is connected the blue STATUS LED turns on. It turns off after
disconnect.
7. External output format
7.1. Bluetooth® communication specifications
Bluetooth® version Ver. 3.0
Communication method AFH
Modulation system GFSK
Radio output power 4 dBm
Transmission power class
Class 2
Profile SPP
Communication distance
Approx. 10 m*
Acquisition condition TELEC, FCC, IC, CE, SRRC, NTC, NCC, ANATEL, KC, WPC
*Communication distance varies depending on the performance of the radio wave
environment and communication connection partner device.
7.2. Communication conditions
Baud rate
Bluetooth® Depend on a host device
PC/ USB 2400, 4800, 9600, 19200 bps
Parity None
Data length 8 bit
Stop bit
1 bit
Flow control Hardware (RTS/CTS)
※ Bluetooth® may be required to enter PIN code or passcode by the connecting device.
In this case, enter "0000".
※ When using optional USB (USB connector corresponding serial output) cable, catalog
#584, driver software is required to be installed on your PC.
