7.3. Communication format
 When set “M3+ID” for communication format setting
※ The “7 digits ID” can be changed by the command from external device.
(Default: Serial number of CEM3-G-BTA)
 When set “M-3” for communication format setting
7.4. Input commands
The settings can be changed from external if send the commands. The tool has to be no
torque loaded when changing the setting.
When send more than 2 commands continuously put the interval more than 200 [ms].
The tool respond external device the response command after process the action.
※ Commands are ASCII code.
※ Add the "CRLF" to the end of command.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
R E , 0 0 1 , + 1 0 0 . 0 , n m , + 0 9 0 , d e g , O O ,
33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59
1 2 3 4 5 6 A , 1 6 / 1 2 / 3 1 , 1 2 : 5 9 : 5 9 CR LF
Header
3 digits counter
torque with decimal point
Unit of torque
Angle
Unit of angle Judgment result
7 digits ID
Date (yy/mm/dd)
Time (hh/mm/ss) Delimiter
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
R E , 9 9 9 , 1 0 0 . 0 , 1 6 / 1 2 / 3 1 , 1 2 : 5 9 : 5 9 CR LF
Header
3 digits counter
torque with decimal point
Date (yy/mm/dd)
Time (hh/mm/ss) Delimiter
Input command Action/ Discription Note
AT008,**
Change the torque unit. Send numbers instead of "**".
N
･
m
：
06, kgf
･
cm
：
02, kgf
･
m
：
03,
lbf
･
in
：
08, lbf
･
ft
：
09
AT037,*****,*****
Set the higher and lower limit torque values.
Send torque value with decimal point.
Send the higher limit torque first then lower limit torque.
The higher limit torque value has to be more than lower limit torque
value. ("0" can be set)
AT045,*****
Set the trigger torque value.
Send torque value with decimal point.
It has to be from 5% to 100% of maximum capacity torque.
("0" can be set)
Turn on the angle setting on the tool first by manual.
AT046,***,***,***
Set the double tightening detection judgment angle,
lower limit and higher limit angle settings in this order.
The value is valid between "000" to "999" degrees.
●
Double tightening detection judgment angle:
It can't be set under "MODE-M". In this case, send "000" for it.
●
Lower limit angle:
It has to be more than double tightening detection judgment angle value.
(Can be set "000")
●
Higher limit angle:
It has to be more than double tightening detection judgment angle and
lower limit angle values. (Can be set "000")
※
The trigger torque setting is required to accept above angle settings.
AT023,*******
Set the 7 digits ID number.
Send the capital alphabet or number.
The tool outputs data include this ID.
Response command Discription
RE003,OK Received successfully
RE004,ERROR Received error, settings error
E10
Received error, commands error
(Missing the "AT" on the top of command)
