Tohnichi R-CM User Manual

4
Modular Conversoin Receiver Model: R-CM
1 Outline
This R-CM applied interchangeable radio modules and by attaching a Tohnichi radio module,
it can be used as various Tohnichi wireless Pokayoke receiver. This makes it easy to update the receiver
from a standard tightening counting type error proong torque wrench system to data transmission type
torque wrench by changing the radio module of receiver.
In addition, it is equipped with relay contact output terminals and a RS232C output. It allows to manage
the tightening count signal by an optional count checker CNA-4mk3 or manage the tightened torque
value through RS232C to PC/PLC, it is possible to establish a preventing missed tightening system with
traceability.
2
Specications
Model R-CM
Display
Status lamp, LCD
Receiving LED x 4
Input/Output
Relay output x 4
Reset input, LS IN input
RS232C Input/Output
Power
DC24V (18V - 36V) *1
Power consumption: Less than 5W
Case Material Resin
Temperature of Use 0 - 50
℃
Less than 85%RH (No condensation)
Radio Frequency Depends on a mounted radio module * 2
Communication
Distance
Depends on a mounted radio module * 2
Radio License Depends on a mounted radio module * 3
Standard Accessories No.1070 (DIN rail) Fixturex 2pcs
*1. To use at AC100V ～ 240V, required an optional AC adapter model BA-8R.
*2. For details, refer to operating manual of each radio module.
*3. Consult Tohnichi for status of wireless certication acquisition for each country.

Tohnichi R-CM Specifications

General

Brand	Tohnichi
Model	R-CM
Category	Receiver
Language	English
