TOMCAR TM37E - Page 97

97
Troubleshooting
MAINTENANCE
Electrical Drive System Faults
If an error occurs in the motor controller or BMS it is represented to the driver on the Spyglass display by a number
with the prefix ‘E’.
Example: E00021 – Error code 21.
The following table displays some of the trouble codes that can be checked and solved without contacting your
authorized TOMCAR dealer.
Motor Controller Faults
CODE
Fault name & Effect of Fault
Possible cause
Set/Clear Conditions
14
Pre-charge Failed
Shutdown Motor;
Shutdown Main Contactor;
Shutdown Throttle;
Full Brake;
Open circuit in external pre-
charge resistor or associated
wiring.
Check safety switch (located by
the charge socket) is ON.
Check fuse 16 in traction battery
fuse panel.
Cycle KSI
15
Controller Severe Under temp
Shutdown Motor;
Shutdown Main Contactor;
Shutdown Throttle;
Full Brake;
Controller is operating in an
extreme environment
Bring temperature above -40
o
C.
Cycle KSI
16
Controller Severe Over temp
Shutdown Motor;
Shutdown Main Contactor;
Shutdown Throttle;
Full Brake;
1. Controller is operating in an
extreme environment.
2. Excessive load on vehicle
Bring controller temperature
below 95
o
C.
Cycle KSI
