APPENDIX
REPLACEMENT PARTS & ORDERING INFORMATION
7.4
Table 7.1.1 - Replacement Parts for Model DE89RB-100-US
QTY PART NUMBER DESCRIPTION
1 267302 Filter Screen, 1 1/2” x 6” (38.1 mm x 152.4 mm)
2 328703 Piston Wearband
2 3328-2 Rod Seal
2 3329-2 Rod Bearing
2 3320-4 Hydraulic Cylinder Rebuild Kit
1 318593 Hydraulic Fluid Filter
1 3284-7 Compression Cylinder Piston
2 2043-A1 1/2” Injection Ball Valve
1 2040 Injection Ball Valve Actuator
1 1080-91 Limit Switch
2 3686 Compression Cylinder Pressure Switch
2 3197 Compression Cylinder Pressure Gauge, 0 - 100 psig
1 3192 Hydraulic Pressure Gauge, 0 - 5000 psig
2 3317 Hydraulic Directional Valve Coil
2 3318 Hydraulic Valve Rectifier
2 3747 Delay or Injection Timer
3 3735-1 120V Panel Bulb
1 3336012 Hydraulic Relief Cartridge
