Tool-Temp TT-390 User Manual

Manual of instructions TT-390 33/35
12.2. List components and spare parts
Art.-Nr.
ELD-Code
Description
Comment
1
Fa0800326
Fa0800328
N 1
Digital temperature controller MP-888
Digital temperature controller MP-888
new
revised
2
Fa0900003
Fixing clips for controller MP-888
As a pair incl. straining
screw
3
Wa1000010
B 1
Thermocouple internal
(Temperature probe)
Fe-Ko, cable length
2000mm
4
Gb0700900
F 1
Thermal relay pump 4.0 – 6.0A
5
Gl0200003
Gl0200001
F 7
Fuse 1A primary T1, 6.3 x 32 mm
Fuseholder big
Packing of 10 pieces
6
Gl0200000
Gl0200002
F 8
Fuse 1A secondary T1, 5 x 20 mm
Fuseholder small
Packing of 10 pieces
7
F 7/1
Automatic cut-off 2A, 2-poles
8
Gf0101200
F 10
Capillary pipe thermostat 80°C – 370°C
Tmax
9
Gi0100000
F 15
Level control
Unit off
10
Gl0400400
F 22 / -2 / -3 / -4
Automatic cut-off 16A, 3-poles
11
Gl0400600
F 24 / -2 / -3
Automatic cut-off 32A, 3-poles
220 V
12
Gf0101200
F 35
Level control
Maximum
13
Gf0101200
F 36 / -2
Capillary pipe thermostat 80°C – 370°C
Pre-warning heating
14
Gf0101200
F 59
Capillary pipe thermostat 80°C – 370°C
mould drainage
15
Df0000028
F 64
Sensor flow measurement
Type A
16
Gk0300400
H 4
H 21
Lamp level control – too low (yellow)
Lamp level control – too high (yellow)
Double lamp
17
Gk0300100
H 6
Lamp motor overload (red)
18
Gk0300500
H 7
Lamp safety thermostat (red)
19
Gg0300000
H 15
Horn
20
Gk0300100
H 20
Lamp limit (red)
21
Gk0300300
H 26
Lamp VAC (yellow)
22
Gk0300100
H 36
Lamp safety thermostat for heating
