Manual of instructions TT-390 34/35
23
Gk0300100
H 63
Lamp flow control (red)
24
Gb0101211
Gb0101212
K 1
Contactor 56A pump motor
(main contactor)
Contactor 110A pump motor
(main contactor)
25
Gb0101100
K 3
Contactor 32A
Heating 1
26
Gb0101100
K 4 / -2 / -3
Contactor 32A
Heating 2 - 4
27
Gb0705801
K 23
Time delayed relay RR-900
28
Gb0705002
K 25
Relay standard, 11-poles
29
Gb0706021
K 51
Mini-relay, 8-poles
30
Gb0706021
K 68
Mini-relay, 8-poles
31
Gb0705830
K 72
Time delayed relay RR-930
32
Wb0203005
Wb0203017
-
-
M 1
A-Pump with pump motor 1.8kW
A-Pump with pump motor 1.8kW
A-Pump with pump motor 1.8kW
A-Pump with pump motor 1.8kW
3 x 380 415V 50Hz
3 x 440 480V 60Hz
3 x 575 600V 60Hz
3 x 200 230V 50/60Hz
33
Gg0400100
Gg0400000
P 2
Working hour meter 50Hz
Working hour meter 60Hz
34
Gk0700800
Q 1
Main switch 63A
without locking
35
Wa0100000
Wa0100001
Wa0100002
R 1 / 2 / 3
Heating 8000 Watt
Heating 8000 Watt
Heating 8000 Watt
3 x 220 -230V
3 x 380 420V
3 x 440 480V
36
Gk0300704
S 1 / H 1
Switch unit "ON-OFF"
37
Gk0300704
S 2 / H 2
S 3 / H 3
Switch heating 1
Switch heating 2 4
38
Gk0600200
S 4
Switch Thermocouple/Fe-Ko
39
Gk0300701
S 5 / H 5
Switch horn
40
Gk0200100
Gk0200200
S 7
Switch Pump BAR / VAC
Switch Pump BAR / VAC
complete
only the red front part
41
Gk0500100
S 10
Press button mould drainage
42
Gc0100600
T 1
Transformer control 70VA
43
Gn0700000
X 1
Socket for thermocouple/Fe-Ko
