Tool-Temp TT-390 User Manual

Manual of instructions TT-390 35/35
44
Df0200200
Df0200903
Df0200600
Y 1
Solenoid valve 1“
Repair kit for solenoid valve 1“
Trip coil 230V 50/60Hz
water cooling
material: membrane,
spring, tappet
Ø 12 mm
45
Df0200110
Df0200910
Df0200600
Y 15
Solenoid valve 1/4“ (18 bar)
Repair kit for solenoid valve 1/4“ (18 bar)
Trip coil 230V 50/60Hz
mould drainage
material: spring and
tappet
Ø 12 mm
46
De0701300
De0701200
Manometer -1 up to 9 bar
Fixing clips for manometer
Ø 62 mm
85 x 30 x 2 mm
47
De0100300
Waterfilter 1” with mesh bottom
Cooling water inlet
48
De0202800
Non-return flap R 3/8”
Mould drainage
49
De0200110
Non-return flap R 1”
Cooling
50
Ca2000500
Screwed cap for manual refill pipe 1”
51
De0300700
Drain angle 1/2”
52
De0300004
Stop valve 1/2”
53
De0203800
Non-return valve 1”
54
Dc0100400
Steering rollers Ø 100 mm
With 4 mounting holes
55
Bb0300500
Clip fastener for side panels
(clip, knop, base and
screw nut M5) Packing of
5 pieces
56
Bb0300100
Door locking
For electrical cabinet door
57
Insulation-Set
