Top Photon - Page 12

Rubber Foam
BAG G PO-SDT026RD-1 44.5mm Universal Bone (Alloy) x 2 x 4
PO-SDT009RD-1 46mm Universal Bone (Alloy) x 2
PO-SDT018-1 Universal Axle x 4 x 4
PO-SDT011-A-1 Universal Insert x 4 x 4
PO-DT0011-1 2 x 10mm Universal Pin x 4 x 4
PA-SS0303BK-1 M3x3mm Set Screw x 4 x 4
Page 12
STEP 13 (con’d)
UPPER CHASSIS (con’d)
STEP 14
P
13
(con d)
STEP 13
FINISHED
UNIVERSALS
PO-SDT026RD-1
STEP 14A: Make 4 alloy universals for
foam edition and 2 for rubber edition.
PO-SDT018-1
PO-SDT011-A-1
PO-DT0011-1
PA-SS0303BK-1
STEP14B: Make 2 alloy
universals for rubber edition.
PO-SDT009RD-1
PO-SDT018-1
PO-SDT011-A-1
PO-DT0011-1
PA-SS0303BK-1
Amendment: from STEP 14B onward,
PO-SDT009RD-1 should be “red” in color.
