Topcom Butler E700 - Installing the Charger

4
Getting started
1.3 Installing the charger (Only for Butler E700 Twin/Triple/Quattro)
Plug one end of the adaptor in the power outlet and the other end into the adaptor jack at the bottom
of the charger.
1.4 Keys / LED’s
Handset
Earpiece speaker
Display
Esc / Mute key
Up / call log key
Power on-off / on-hook key
Alphanumeric keys
Ringer on-off
INT key
Microphone
Handsfree-key
Redial key
Keypad lock key
Down / Phonebook key
Off-hook / Recall key
Menu / OK key
A
- 1C Charger -
A. Adaptor with power cable
1
2
3
4
5
7
8
9
10
6
11
12
15
14
13
- 1D Handset -
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
