10
5. BASIC OPERATION
Remaining Battery Power
The remaining battery power is displayed in four levels.
• The battery operating time will vary depending on the environmental conditions, such as ambient
temperature etc. Prepare spare batteries in advance to minimize disruption to measurement.
"6. USING THE BATTERY"
Display of version number and angle measurement accuracy
Press {FUNC} to enter Function Mode, and then press {0 SET} to display the version number. In Version
Display Mode, the software version information on the top line and the angle measurement accuracy
information on the second line are displayed.
Measurement is possible.
Measurement is impossible.
Replace batteries.
Remaining battery power
V 90°10’20”
TILT
HR 123°40’50”
{FUNC}
V 90°10’20”
HR 120°30’40”
V 90°10’20”
HR 120°30’40”
1.00 00
CLASS 5”
{0 SET}
After these settings are displayed for three seconds, the screen
automatically returns to the previous screen.
