9. ANGLE MEASUREMENT
1. Press {FUNC} to go function mode screen.
2. Press {REP} to go repetition angle measurement mode.
3. Sight the target “A”, and press {0SET} twice to become 0°.
4. Sight the target “B”, and press {HOLD}.
5. Sight the target “A” again and press {R/L}.
6. Sight the target “B” again, and press {HOLD} to finish 2
measurements.
7. Repeat procedures 5 and 6 for the desired number of
repetitions.
8. To finish repetition measurement, press {FUNC} then press
{HOLD}.
• Only horizontal angle right measurement can be carried out in the repetition angle mode.
• Horizontal angle can be accumulated up to 2000°00'00" – minimum reading (horizontal angle right).
In case of 5" reading, horizontal angle can be accumulated up to +1999°59'55".
• When the discrepancy value of each measurement is more than ±30", error code “E04” is displayed. Press
{0SET}, and start measurement again.
• Up to 19 measurements can be made.
The first digit "1" will be omitted from the measurement number for the 10th measurement onwards.
9.5 Repetition Angle Measurement
F
V 90°10’20”
HR 120°30’40”
Ht 45°10’00”
1AVG
H 45°10’00”
Ht 90°20’00”
2AVG
H 45°10’00”
Total angle
Average angle
2 measurements
The number of
measurements
Ht 180°40’00”
4AVG
H 45°10’00”
Example: 4 measurements
To Next Page
