92
4 STANDARD MEASUREMENT MODE
4.7 Data output of IS series
The information of IS series regarding tracking auto-tracking are added to the protocol of Topcon Total
Station system so far.
Also you can add utility information such as battery remaining, EDM mode, auto-tracking mode, normal/
reversed face information, Tilt information if you like. For selecting, refer to Chapter 6 “PARAMETERS
SETTING MODE” .
During an utility function selection, measurement will be continued whenever tilt over. The tilt over will
not be compensated here.
In case tilt over, the tilt information will be displayed on the right-lower screen as the following marks
during the utility function is selected.
• Control by interface for Topcon AP-L1A system, see Chapter 5.5 “AP-L1A Communication
Emulator” .
Marks Status of tilt
[t] Under tilt compensation
[?] Tilt Over
[
*
]
Tilt OFF
Tilt information
