Topcon RC-2W - Nomenclature and Functions: RC-2 RW

Nomenclature and Functions
6
Nomenclature and Functions
Remote Controller RC-2RW
Emitting window
Operating keys
Receiving window
DM pole
Prism unit A3/A3S
Bottom
Battery cover
Battery cover lever
Serial signal
RS-232C
connector
Rear side
(Optional accessory)
Hook for holder
Screw hole for holder
(Laser beam aperture)
Connector for holder RC-2B
Holder RC-2B for prism unit A3/A3S
RC-2RW fixing screw
RC-2RW
(When using Bluetooth
communication)
