OBJECTIVE OPERATIONS
9 When the positional relation between the instrument body and the patient's eye is proper
for photography, the instrument automatically takes a picture.
When flares appear in the peripheral section, the instrument does not take a picture
automatically even if the auto shoot function is ON.
Check the bright spot on the color LCD monitor and press the photography switch to
take a picture.
When the auto shoot function is OFF, the instrument does not take a picture automati-
cally.
Check the bright spot on the color LCD monitor and press the photography switch to
take a picture.
If you cannot align the split lines into one line by operating the focusing knob, change the
diopter compensation lens.
For details, see "Changing the diopter compensation lens" on page 40.
Since the split lines are off when the diopter compensation lens is anything other than
(0), turn the focusing knob so that the fundus image is clearly visible on the color LCD
monitor.
If the split lines cannot be seen, check if the eye is obstructed by eyelashes or the eyelid.
Upon condition that the digital magnification mode is set, when the auto small pupil func-
tion is ON and small pupil is detected or when you take a picture by pressing the switch,
the image is stored with the digital magnification 30° in IMAGEnet, etc. When the image
is printed in this setting status, it is printed with the digital magnification 30°. When
shipped, the digital magnification mode is not set. For details, contact your dealer or
TOPCON (see the back cover).
