TRL-35 Configuration
TRL-35 Operator’s Manual
2-10
•Mode
The Radio Operation mode. To set the TRL-35 into
transmit mode, choose Transmitter as the Mode. In
Simplex protocol, the TRL-35 currently supports
operation as a Transmitter, Receiver, or Repeater.
•Link Rate
The default link rate for DBPSK is 9600 and is recommended
for most applications. The link rate is the rate at which data is
transmitted over the RF Link.
•
Output power
Select the level of power for RF transmissions ranging
from 500 mW to 32W (45 dBm).
10. Click on the Serial Interface tab.
Figure 2-11. Serial Interface Screen
Table 2-1. Modulation Type for Link Rate
For Link Rate Use Modulation Type
4800 baud DBPSK
9600 baud (default; recommended) DBPSK (recommended) or DQPSK
19200 baud DQPSK
