TRL-35 Receiver Specifications
P/N 7010-0815
A-3
TRL-35 Receiver
Specifications
TRL-35 Environmental
Specifications
Table A-3. RL-35 Receiver Specifications
Parameter Specification
Noise Figure 5 dB
Receiver Sensitivity for DBPSK (@
BER <1x10
-4
, over temperature -30°C to
+60°C, 25/12.5 kHz
GMSK -113 dBm @ 25kHz/-114 dBm
@ 12.5 kHz
DBPSK -113 dBm @ 25kHz/-114 dBm
@12.5 kHz
DQPSK -110 dBm/ -111 dBm 12.5 kHz
D8PSK -106 dBm @25kHz/-107 dBm
@ 12.5 kHz
D16QAM -100 dBm @25 kHz/-101
dBm @12.5 kHz
Adjacent Channel Selectivity -70 dB for 25 kHz Channel Spacing
-60 dB for 12.5 kHz Channel Spacing
Nominal Input Impedance 50 Ohms
Co- Channel Rejection 25/12.5 kHz -8/-12 dB
Adjacent Channel Selectivity 25/12.5
kHz
70/60 dBc
Table A-4. TRL-35 Environmental Specifications
Parameter Specification
Temperature Operating -30°C to + 60°C
Storage -40°C to + 85°C
Environmental IP 66
Dimensions 6” x 2.9” x 2.8” D
Weight 27 oz
Power Supply Voltage +9 to +16 Vdc nominal
