Specifications
TRL-35 Operator’s Manual
A-2
TRL-35 Transmitter
Specifications
Table A-2. RL-35 Transmitter Specifications
Parameter Specification
Output Power GMSK - 33 dBm to 45 dBm in 1dB
Steps (2W to 35W)
DBPSK – 33 dBm to 45 dBm in 1dB
Steps (2W to 35W)
DQPSK – 33 dBm to 45 dBm in 1dB
steps (2W to 35W)
D8PSK – 28dBm to 40 dBm in 1dB
steps (650 mW to 10W)
D16QAM – 25 dBm to 37 dBm in 1 dB
steps (320 mW to 5W)
Nominal Output Impedance 50 Ohms
Output Power Control Accuracy + 1.5 dB (at normal test condition)
Carrier Frequency Stability +/- 1.5ppm initial stability over temp
with +/- 3.0 ppm aging/year
Max Frequency Error +/- 1.0 kHz (at normal test conditions)
Adjacent Channel Power (conducted) 65dB
