Configuring the TRL-35
P/N 7010-0815
2-7
As a Transmitter in
Modem-TPS in Simplex Protocol
The TRL-35 provides high powered TX communications from the
base station to the rover. To configure the UHF radio modems, have
the following ready:
• PC running Windows 98, 2000, NT, or XP
• Modem-TPS 2.2p0 or later
• TRL-35 Programming cable, Topcon P/N 14-008107-01LF
• TRL-35 Power cable, Topcon P/N 14-008110-01
1. Connect the computer and TRL-35 using the TRL-35
programming cable.
2. Connect the power cable to the TRL-35 and confirm that the
power LED is on.
3. Open Modem-TPS.
4. On the connection dialog box click Cancel.
5. Go to Tool s Options (Figure 2-4 on page 2-4).
To comply with RF exposure requirements,
maintain at least 25cm between the user and the
radio modem.
Before connecting power to the TRL-35 confirm
the modem antenna is attached.
