Configuring the TRL-35
P/N 7010-0815
2-11
11. On the Serial Interface screen, select a baud rate for the modem’s
serial port. The same rate must be used for both the receiver and
the transmitter. The recommended baud rate is 38400.
12. Select the RTS/CTS (Ready to Send/Command to Send) as ON.
13. Click Apply.
14. Click on FileDisconnect.
15. To close Modem-TPS, choose FileExit.
16. Launch PC-CDU with the TRL-35 connected to a receiver and
setup the receiver to run as an RTK Base station.
As a Repeater in Modem-TPS in
Simplex Protocol
The TRL-35 provides high powered TX communications from the
base station to the rover. To configure the UHF radio modems, have
the following ready:
• PC running Windows 98, 2000, NT, or XP
• Modem-TPS 2.2p0 or later
• TRL-35 Programming cable, Topcon P/N 14-008107-01LF
• TRL-35 Power cable, Topcon P/N 14-008110-01
1. Connect the computer and TRL-35 using the TRL-35
programming cable.
2. Connect the power cable to the TRL-35 and confirm the power
LED is on.
3. Open Modem-TPS and on the connection dialog box, then click
Cancel.
NOTE
To comply with RF exposure requirements,
maintain at least 25cm between the user and the
radio modem.
NOTE
Before connecting power to the TRL-35 confirm
the modem antenna is attached.
