TorcUP AP1000 - Table of Contents; Manual Index

Operational and Maintenance Manual for TorcUP
AP1000
Version 1: 2013 April
Heavy duty air motor. Powerful 4HP industrial air motor runs on 60cfm/100PSI
Disconnect removable pressure gauge. Quadra-Torc function (optional). Quick connect couplers.
Supplied with dual non-conductive high pressure hose with couplers.
TorcUP Inc. is not responsible for customer modication of tools for applications on
which TorcUP Inc. was not consulted.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING PUMP.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION IN THIS
MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
The use of other than genuine TorcUP replacement parts may result in safety
hazards, decreased tool performance, and increased maintenance, and may
invalidate all warranties. Repairs should be made only by authorized
personnel. Consult your nearest TorcUP Authorized Service Center.
Refer All Communications to the Nearest TorcUP Ofce or Distributor.
For Technical Support & Information Contact:
TorcUP Inc.
1025 Conroy Place, Easton, PA 18040 USA
Phone: +1 610-250-5800 Fax:+1 610-250-2700
email: sales@torcup.com
Manual Index……………………................1
General Warnings………………………….2
Safe and Correct Use…………………......3-6
Technical Specications…………….……5-8
Working Pressure………………….....……5
Install Vent Plug……………………..….…..6
Adding Oil…………………………….....…..6
Connecting Hydraulic Tools……………...6
Pump Mounting………………………….....6
Air Control Buttons........……………………...7
Pressure Torque Setting……………………...7
Air Motor and Filter Lubricator......................8
After Completing the Job……………………..8
Periodic Maintenance………………………....9
Maintain Oil Level…………………………...….8
Clean Oil Intake Screen…………………...…..9
Flushing the Pump………………………….… 9
Trouble Shooting............................................10
AP1000 Parts Index……………………………11-23
CONTENTS
TorcUP has taken every care in preparing this Operational Manual that is intended as a technical guideline only.
TorcUP accepts no liability in relation to any use or reliance made of any information in this Operational Manual.
All information, illustrations and specications in this Operational Manual are based on the latest information avail-
able at the time of publication. The right is reserved to make changes at any time without notice.
Equipment operators and installers shall be responsible for ensuring that a safe working environment and safe
systems of work are in place before operating the equipment.
1
