TorcUP AP1000 - RESERVOIR; 1.5 GALLON RESERVOIR; 2.5 GALLON RESERVOIR

RESERVOIR
Reservoirs
AP-1000 Torque Wrench
Power Pump
(46213P) 2.5 GALLON RESERVIOR
(45996P) 1.5 GALLON RESERVIOR
NOTE: ALL RESERVOIRS ARE POWDER COATED BLACK
NOTE: THIS ILLUSTRATION IS FOR REFERENCE ONLY.
THE APPEARANCE OF YOUR UNIT MAY DIFFER
FROM UNIT SHOWN.
1.5 GALLON RESERVOIR
ITEM # DESCRIPTION 1.5 GALLON 2.5 GALLON QTY.
03 RESERVOIR 45996P 46213P 1.00
04 RESERVOIR GASKET 85469 85469 1.00
05 BREATHER VENT 3/8" NPT 46348 46348 1.00
06 PIPE PLUG 46697 46697 1.00
07 SAE #12 HEX PLUG WITH PORT 46118 46118 1.00
08 HHCS 1/4-20 x 3/4 LG PLATED 65891 65891 14.00
09 SEALING WASHER 65892 65892 14.00
10 RESERVOIR DECAL 46052 46052 1.00
52 SIGHT GAUGE 46009 46009 1.00
73 COVER PLATE 46334 46344 1.00
10
6
1,1 Kw
1 hp
1/2
46052
3
52
98
73
5
7
4
AP-1000
PART# 45996P 1.5 GALLON RESERVOIR
PART# 46213P 2.5 GALLON RESERVOIR
