TXU-16 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-16-L01 1
2 Side Plate - Right TX-16-L02 1
3 Drive Plate TX-16-L03 1
4 Drive Pin TX-16-L05 1
5 Drive Pin Spring TX-16-L07 1
6 Ratchet TX-16-L09 1
7 Drive Segment TX-16-L11 1
8 Upper Spacer TX-16-L13 1
9 Middle Spacer TX-16-L14 1
10 Lower Spacer TX-16-L15 1
11 Spacer Pin TX-16-L17 2
12 Sideplate Sleeve TX-16-L19 2
13 Shroud TX-16-L21 1
14 Segment Spring TX-16-L25 1
15 Upper Spacer Screw TX-16-L27 4
16 Lower Spacer Screw TX-16-L29 4
17 Shroud Screw TX-16-L31 2
18 Drive Pin Spring Roll Pin TX-16-L33 1
19 Spacer Roll Pin TX-16-L35 1
