ASSEMBLY OF THE TOOL
1. With the cylinder assembly in one hand and the ratchet link in the other, hook the notch on the
shaft of the cylinder piston rod (2) onto the link drive pin (4) and bring the two assemblies together.
2. Insert the link pin (9) into the hole in the link side plate (1 or 2) until the cylinder piston rod (2) snaps
into the annular groove around the center of the link pin.
MAINTENANCE SECTION
13. Place the left side plate sleeve on the hub of the ratchet and align the screw holes for the spacers.
14. After applying a non-permanent, thread-locking compound to the threads. Use hex wrenches to
install the two remaining lower spacer screws.
