11
TECHNICAL SPECIFICATIONS
Charger Requirements: 110 - 120 V (50-60 Hz) and 230 - 240 V (50-60 Hz)
MODEL NUMBER
VOLTA
500
VOLTA
1000-1
VOLTA
1000
VOLTA
2000
VOLTA
3000
VOLTA
6000
SQUARE DRIVE 3/4” 3/4” 1” 1” 1” 1.5”
MIN. TORQUE (lbf-ft) 120 240 240 500 750 1200
MAX. TORQUE (lbf-ft) 500 1000 1000 2000 3000 6000
MIN. TORQUE (Nm) 160 330 330 680 1020 1630
MAX. TORQUE (Nm) 680 1360 1360 2710 4070 8130
HEIGHT A (w/ battery) (in) 10.57 10.54 10.54 10.54 10.76 11.38
HEIGHT A (w/ battery) (mm) 268.48 267.67 267.67 267.67 273.18 289.05
LENGTH B (in) 7.65 9.08 9.28 9.72 12.49 13.17
LENGTH B (mm) 194.28 230.73 235.59 246.84 317.14 334.42
DIAMETER C (in) 3.32 2.85 2.85 3.10 3.75 5.00
DIAMETER C (mm) 84.25 72.39 72.39 78.64 95.25 127
WEIGHT (w/o reaction arm & battery) (lbs) 6.6 9.15 9.6 11.2 17.7 33.5
WEIGHT (w/o reaction arm & battery) (kg) 2.99 4.15 4.35 5.08 8.03 15.19
WEIGHT (w/ reaction arm & battery) (lbs) 10.85 13.4 14.65 16.25 22.75 43.3
WEIGHT (w/ reaction arm & battery) (kg) 4.92 6.08 6.64 7.37 10.32 19.64
RPM at Min. Torque 12.25 4.5 4.5 2.9 1.5 0.9
RPM at Max Torque 17.5 6.75 6.75 4.25 2 1.2
