20
WIRING DIAGRAMS FOR EWZ201C
LN
PULSE
120/277VAC
CH1
TIMER
SUPPLY
CH2
ON
PULSE
OFF
UNIT MUST BE CONFIGURED
FOR MOMENTARY OPTION
TO MECHANICALLY HELD
PULSE TYPE CONTACTOR
L
SPST SPST
LN N
120/277VAC
CH1
TIMER
SUPPLY
NL L
LOAD LOAD
CH2
SPST SPST
