Tormach PATHPILOT OPERATOR CONSOLE User Manual

INSTALL THE CONTROLLER ARM
7. With a 21 mm wrench, remove the monitor bracket from the Controller Arm, and rotate it so that the
largest mounting plate is facing up.
Figure 3: Incorrect and correct orientations of the monitor bracket on the Controller Arm.
Note: The largest mounting plate is for the monitor, and the smallest mounting plate is for the
keyboard tray.
