Tormach PATHPILOT OPERATOR CONSOLE User Manual

INSTALL THE PATHPILOT OPERATOR CONSOLE
INSTALL THE PATHPILOT OPERATOR CONSOLE
Tools and Items Required
l 16 mm wrench
l Metric hex wrench set
l Phillips screwdriver
1. Put the operator console against the monitor mounting plate and align the holes. Attach the operator
console and monitor mounting plate together with four M4 × 12 mm socket head cap screws (provided with
the operator console).
Figure 5: Operator console attached to the monitor mounting plate.
Page 6
©Tormach® 2023
Specifications subject to change without notice.
tormach.com
TD10788: Installation Guide: PathPilot Operator Console Assembly for 8L (0123A)
