6. Attach the Coolant Trays
After the mill is bolted to the stand it is time to attach the
coolant trays. Position the trays near the stand. Figure 12
Test fit the coolant trays. The left and right trays are different.
You may need to run a tap into the holes to clean the paint out
of the threads.
It is very helpful to have another person help position the
tray and to hold it in place Figure 13. Prior to attaching the
tray to the stand with the mounting bolts apply a small
amount of silicone caulk to each bolt hole.
Figure 13. Setting coolant tray in place.
Figure 12. shows mill with right side tray being
installed.
